2.83 “ Small Size 200 RGB×648 Dots TFT LCD Display Module Screen

Short Description:

Model No: N283-2064KIWPG03-C14Size: 2.83 inch

Pixels: 200(H)RGB x 648(V)

A.A: 21.42(H) x 69.4（V)

Outline: 24.42(H) x 74.7(V) x2.42(D)

View Direction: All View

Interface: SPI 4 LINE

Brightness(cd/m²): 350

Driver IC: GC9B72

Touch Panel: Without Touch Panel

Send email to us Download as PDF

Product Detail

Product Tags

N283-2064KIWPG03-C14 is a small-sized 2.83-inch IPS wide-angle TFT-LCD display module. This small-sized TFT-LCD panel has a resolution of 200RGB*648 pixels, The display module is built-in with GC9B72 controller IC, supports SPI 4 LINE interface, a supply voltage (VDD) range of 2.4V~3.3V, module brightness of 350 cd/m² (typical value), and contrast of 1200(typical value).

This 2.83 inches TFT- LCD display module is portrait mode, and the panel adopts wide angle IPS (In plane Switching) technology. The viewing range is left: 80/right: 80/up: 80/down: 80 degrees. The panel has a wide range of perspectives, bright colors, and high-quality images with saturated nature. It is very suitable for applications such as wearable devices, handheld devices, security monitoring system. The operating temperature of this module is -20 ℃ to 70 ℃, and the storage temperature is -30 ℃ to 80 ℃.

General Description

Display Type	IPS-TFT-LCD
Brand name	WISEVISION
Size	2.83 inch
Pixels	200(H)RGB x 648(V)
View Direction	All View
Active Area (A.A)	21.42(H) x 69.4V)
Panel Size	24.42(H) x 74.7(V) x2.42(D) mm
Color arrangement	RGB Vertical stripe
Color
Brightness	350 (Min)cd/m²
Interface	SPI 4 LINE
Pin Number	14
Driver IC	GC9B72
Backlight Type	6 WHITE LED
Voltage	2.4~3.3 V
Weight	TBD
Operational Temperature	-20 ~ +70 °C
Storage Temperature	-30 ~ +80°C
