0.72 “ Small Size 60 RGB×160Dots TFT LCD Display Module Screen
N072-0616TBBIG45-H10 is a TFT-LCD Module with a 0.72-inch diagonal round screen and a resolution of 60*160 pixels. This round LCD screen adopts an SPI panel, which has the advantages of higher contrast, a full black background when the display or pixel is off, and wider viewing angles of Left:80 / Right:80 / Up:80 / Down:80 degrees (typical), 1500:1 contrast ratio (typical value), 350 cd/m² brightness (typical value), and an anti-glare glass surface.
The module is built-in with GC9D01 driver IC that can support via SPI interfaces. The power supply voltage of LCD is from 2.5V to 3.3V, the typical value of 2.8V. The display module is suitable for compact devices, wearable devices, home automation products, white products, video systems, medical instruments, etc. It can be operating at temperatures from -20℃ to+60℃ and storage temperatures from -30℃ to +80℃.
General Description
| Display Type | IPS-TFT-LCD |
| Brand name | WISEVISION |
| Size | 0.72 inch |
| Pixels | 60×160 Dots |
| View Direction | All View |
| Active Area (A.A) | 6.41*17.09 mm |
| Panel Size | 8.52(H) x 21.695(V) x1.47(D)mm |
| Color arrangement | RGB Vertical stripe |
| Color | |
| Brightness | 350 (Min)cd/m² |
| Interface | SPI |
| Pin Number | 10 |
| Driver IC | GC9D01 |
| Backlight Type | 1 WHITE LED |
| Voltage | 2.5~3.3 V |
| Weight | 1.1 |
| Operational Temperature | -20 ~ +60 °C |
| Storage Temperature | -30 ~ +80°C |
Mechanical Drawing
What we can do
Wide range of display: Including Monochrome OLED,TFT,CTP;
Display solutions: Including make tooling,customized FPC,backlight and size;Technical support and design-in
Our advantages
A deep and comprehensive understanding of the end applications;
Cost and performance advantage analysis of various display types;
Explanation and cooperation with customers to decide the most suitable display technology;
Working on the continuous improvements at process technologies, product quality, cost saving, delivery schedule, and so on.
FAQ
Q: 1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q: 2. What is the lead time for sample?
A: Current sample needs 1-3 days, customized sample needs 15-20 days.
Q: 3. Do you have any MOQ limit?
A: Our MOQ is 1PCS.
Q: 4.How long is the warranty?
A:12 Months.
Q: 5. what express do you often use to send the samples?
A: We usually ship samples by DHL, UPS, FedEx or SF. It usually takes 5-7 days to arrive.
Q: 6. What's your acceptable payment term?
A: Our usually payment term is T/T. Others can be negotiated.
